6.95" Kenwood Digital Multimedia Receiver with Bluetooth - DMX706S

Discontinued

6.95" Kenwood Digital Multimedia Receiver with Bluetooth - DMX706S

$699⁰⁰

as low as
$116.50

Per month over
6 months.

Apply Now

Available to order

DMX706S
CLEARANCE
DISCONTINUED
Best Deal Promise
Low Stock : Order Soon

Literature

Description
Features

6.95" WVGA Monitor
Apple CarPlay™ & Android Auto™ Ready
High-Resolution Audio Ready
High Quallity Audio Parts
Short Chassis
Dual Camera Inputs
Built-in Bluetooth
3 Preouts 4V

Smartphone Connectivity

Enjoy convenient control of popular apps like Spotify and Pandora, built-in Bluetooth for hands-free calls and streaming music, as well as the ability to use your smartphone like a wireless remote control.

The Best Audio Experience

Sound quality enthusiasts will love the playback support of various types of music formats, including compatibility with FLAC files. Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.

Safe Driving

Keeping you safe on the road ahead is our top priority.

SiriusXM Radio Ready

Access additional music, sports and entertainment content on the go with SiriusXM Radio. (Optional SiriusXM tuner required, sold separately)

USB I/F Section
Frequency response - 44.1k Sampling	20 - 20,000 Hz
Monitor Section
Back lighting	LED
Pixel arrangement	RGB striped arrangement
Effective pixels	99.99%
Number of pixels	1,152,000 800H x 480V x RGB
Drive system	TFT active matrix system
Display system	TN LCD panel
W x H	156.6 mm x 81.6 mm , 6-3/16 x 3-3/16 inch
Picture size	6.95 inches(diagonal) wide
USB I/F Section
USB Standard	USB2.0 High Speed
File System	FAT 16/32, exFAT, NTFS
Maximum Power Supply Current	DC5V=1.5A
D/A Converter	24/32Bit
Audio Decoder	MP3 / WMA / AAC / WAV / FLAC / Vorbis
Video Decoder	MPEG1/2,MPEG4 / WMV / H.264 / MKV
Frequency response - 192k Sampling	20 - 88,000 Hz
Frequency response - 96k Sampling	20 - 44,000 Hz
Frequency response - 48k Sampling	20 - 22,000 Hz
General
Weight - Main unit	1.1 kg 2.4 lb
Operational temperature range	-10°C to +60°C
(with Sleeve)	182mm x 112mm x 73mm 7-3/16 x 4-7/16 x 2-7/8 inch
Installation Dimensions WxHxD	178mm x 100mm x 75mm 7 x 3-15/16 x 2-15/16 inch
Maximum Current consumption	10A
Operating voltage	12V DC Car Battery
Connectivity
Speaker Impedance (Ω)	4-8 Ohms
Preout impedance (Ω)	=< 600 Ohms
Preout level (V)	4V / 10kOhms
Output frequency band	20 - 88,000Hz
Typical Power Output (Front&Rear)	Full Bandwidth Power (at less than 1%THD) 22Wx4
Maximum Power Output (Front&Rear)	50Wx4
Video
Audio Output level (Mini jacks)	1.2 V / 10 kOhms
Video Output level (RCA jacks)	1 Vp-p / 75 Ohms
Video Input level (RCA jacks)	1 Vp-p / 75 Ohms
External audio max input level (Mini jacks)	2 V / 25 kOhms
External video input level (Mini jacks)	1 Vp-p / 75 Ohms
Color system of external video input	NTSC/PAL
AM
Usable sensitivity	28dBμ
Frequency Range (Frequency step)	530kHz - 1700kHz (10kHz)
FM
Stereo separation	45dB (1kHz)
Selectivity	Over 80dB (±400kHz)
S/N (dB)	75dB (MONO)
Frequency response (±3.0dB)	30Hz - 15kHz
DIN S/N 46dB	1.13μV / 75Ohms
Quieting sensitivity	10.2dBf
S/N30dB	0.8μV/75Ω
Usable sensitivity	9.3dBf
DSP Section
Position - Gain	-8 to 0dB
Position - Subwoofer Level	-50 to +10dB
FM
Frequency Range (Frequency step)	87.9MHz - 107.9MHz (200kHz)
DSP Section
Position - Front / Rear /Subwoofer Delay	0 - 20.01ft (0.03or0.04ft Step)
3Way X'Over - SLOPE	-12/-18/-24[dB/Oct.]
3Way X'Over - LOW PASS FILTER frequency	30/40/50/60/70/80/90/100/120/150/Through[Hz]
3Way X'Over - SLOPE	-12/-18/-24[dB/Oct.]
3Way X'Over - Band PASS FILTER frequency	Through/50/60/70/80/90/100/120/150/180/220/250/300[Hz] 250/300/1k/1.6k/2.5k/4k/5k/6.3k/8k/Through
3Way X'Over - SLOPE	-12/-18/-24[dB/Oct.]
3Way X'Over - HIGH PASS FILTER frequency	250/300/1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k
2Way X'Over - SLOPE	-6/-12/-18/-24[dB/Oct.]
2Way X'Over - LOW PASS FILTER frequency	30/40/50/60/70/80/90/100/120/150/180/220/250/Through[Hz]
2Way X'Over - SLOPE	-6/-12/-18/-24[dB/Oct.]
2Way X'Over - HIGH PASS FILTER frequency	Through/30/40/50/60/70/80/90/100/120/150/180/220/250[Hz]
Graphics equalizer - Gain	-9/-8/-7/-6/-5/-4/-3/-2/-1/0/1/2/3/4/5/6/7/8/9[dB]
Graphics equalizer - frequency (Hz) (BAND1-13)	62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k
Graphics equalizer - BAND	13Band
Bluetooth Section
Profile	HFP (V1.7) (Hands Free Profile) SPP (Serial Port Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (V1.6) (Audio/Video Remote Control Profile) PBAP (Phonebook Access Profile)
Multi Profile Support	Multi Profile
Audio Codec	SBC / AAC
Maximum Communication range	Line of sight approx.10m(32.8ft)
USB I/F Section
Total harmonic distortion 1kHz	0.0001%
Signal to Noise ratio	98.5dB
Dynamic range	89dB
Bluetooth Section
Technology	Bluetooth Ver4.1
Frequency	2.402 – 2.480 GHz
RF Output Power (E.I.R.P.)	+4dBm (MAX), Power Class 2
