The M600-5 is a 600 watt marine grade “all-in-one” amplifier featuring four full-range stereo channels and a dedicated mono subwoofer channel.
Overview
The Prime M600-5 is a 600 Watt amplifier specifically designed for Marine and Motorsport applications through its 2-part epoxy coated Printed Circuit Board (PCB). The four stereo channels feature Class-A/B topology and the dedicated subwoofer channel runs on high efficiency Class-D. High level and low-level RCA inputs allow for flexibility and the on-board Punch EQ, built-in 12dB crossovers, and independent gain controls permit precise tuning. Real time output and thermal sensing along with current and short circuit protection protect the amplifier under adverse conditions.
- Class A/B technology (4 channel)
- Class-D technology (sub channel)
- Remote Punch Level Control (sub channel) included
- RCA and high level input with 2/4/5 channel select
- 12 dB/Oct Butterworth crossovers
- On-board Punch EQ with +18dB boost @ 45Hz
- Separate Front, Rear and Sub gain control
- Real time output and power supply thermal sensing
- Cast aluminum heat sink
- 4 Gauge power/ground connectors
- MOSFET power supply
- Over current and short circuit protection
- Marine grade two part epoxy coating on circuit boards
- Muted turn on
- 2-Year Warranty
Technologies
CEA-2006
Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.
Element Ready™ - Amps
These amplifiers are protected against Dust, UV, Corrosion, and feature Stainless hardware.
CE Compliant
This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).
Class-AB
An amplifier topology with the best of both worlds; a Class A preamp and Class B output stage.
Class-D
High efficiency amplifier design that reduces current consumption from the charging system.
| Specifications | |
|---|---|
| Efficiency (average) | Channels 1/2/3/4: 64% @ 4-Ohm Sub Channel: 85% @ 4-Ohm |
| Dynamic Power (PVC/PowerCube®) | 57W x 4 + 221W x 1 @ 4-Ohm 90W x 4 + 390W x 1 @ 2-Ohm 178W x 2 @ 4-Ohm Bridged |
| Shipping Weight | 9.1 Lbs. (4.12 Kg.) |
| Dimensions (H x W x D) | 1.98" x 6.77" x 13.99" (5cm x 17.2cm x 33.5cm) |
| Frequency Response | 20Hz to 20kHz +/-1dB |
| Circuit Topology Class | Class A/B + Class D (Sub) |
| Visual Indicators | Power Protect |
| Remote Controls | Punch Level Control: When connected is linked to "gain control" to provide remote output level |
| Cooling | Convection |
| Speaker Output Connector | Block |
| Heat Sink Type | Cast Aluminum |
| Power Wire Gauge | 4 AWG |
| Signal Input | High Level: 2x 4-pin MOLEX Low Level: 3 RCA Pair |
| Signal Output | - |
| Tone Controls | Front: 0/6/12dB @ 45Hz Rear: 0/6/12dB @ 45Hz Sub: Variable 0dB to 12dB @ 45Hz |
| Number of Channels | 5 |
| Bridgeable | Yes (front/rear channels) |
| Rated Power (RMS Continuous Power) | 50W x 4 + 200W x 1 @ 4-Ohm 75W x 4 + 300W x 1 @ 2-Ohm 150W x 2 @ 4-Ohm Bridged |
| Total Power (Sum of Rated Power) | 600 Watts RMS |
| Crossover Controls | Front Channels: HP/LP Variable 50Hz - 250Hz @ 12dB/octave Rear Channels: HP/LP Variable 50Hz - 250Hz @ 12dB/octave Sub Channel: LP Variable 50Hz - 250Hz @ 12dB/octave |
| Power Input Connector | Block |
| Speaker Wire Gauge | 12 AWG |
