Audiofrog 6 Inch Audiophile Grade Automotive Loudspeaker - GB60
GB60
Literature
Designed to be used in two- or three-way systems, the GB60 can be used in small enclosures or in infinite baffle applications. High power handling, low distortion and 9mm of linear one-way excursion make the GB60 a great foundation of any main speaker system. Mounting depth of under 2-3/4” makes installation in many factory locations possible. Like all the GB Series midrange speakers, the GB60 includes a grille and installation kit that can be customized to blend with or highlight nearly any installation.
Features
- Treated Paper Cone
- 2” (51 mm) Voice Coil on Fiberglass Former
- Milled Flat Single-Layer CCAL Voice Coil, Black Coated for Increased Heat Dissipation
- Copper Inductance- and Distortion-Reducing Pole Piece Cap
- Neodymium Motor with Aluminum Shorting Ring
- Flat, Progressive Nomex® Spider
- Nitrile Butadiene Rubber Surround
- Proprietary Vented Cast Aluminum Basket
- Chrome-Plated Cast Zinc Motor Housing
- Screw Terminals
- All-Metal Grille and Mounting Kits Included
- Multi-Adapter Included for 6-1/2″ and 6-3/4″ Factory Locations
- Hex Screws and Tools Included
- Removable and Paintable Grille
- Rub-On Grille Logos Included for Custom Installation
| Specifications: | |
|---|---|
| Recommended Low Pass Filter Frequency and Slope: | ≤ 3.5 kHz, ≥ 12 dB/oct |
| Peak Power Handling: | 300 W (with recommended crossover) |
| Frequency Response (-3 dB): | 60 Hz – 7 kHz |
| Recommended High Pass Filter Frequency and Slope: | ≥ 70 Hz, ≥ 12 dB/oct |
| Sensitivity (2.83 V/1 M): | 88 dB |
| Recommended Amplifier RMS Power Range: | 20 W – 125 W |
| RMS Power Handling: | 100 W (with recommended crossover) |
| Nominal Impedance: | 4Ω |
