General Features
- RMS POWER Output 4Ω: 200W x 1
- RMS POWER Output 2Ω: 300W x 1
- Dimensions(WxHxD): 5-11/16" x 1-3/4" x 3-7/8"
- Singal Sensing Turn-on
- Conformal Coating *1
*1: Do not install the unit in a spot exposed to direct sunlight or excessive heat or humidity. Also avoid places with too much dust or the possibility of water splashing.
MULTI-APPLICATION
Many of today’s powersports have very limited space to work in and tend to be a harsh environment for electronics because of the exposure to outdoor environments. KENWOOD’s compact performance amplifiers are small in size so they fit even the most limited installation areas. The amplifiers also use a conformal coated main PCB (printed circuit boards) which offer extra layers of protection to help prevent moisture or damp air from damaging the product.
| General | |
|---|---|
| Operating Voltage | 14.4V（11-16V allowable） |
| Dimensions(WxHxD) | '5-11/16 X '1-3/4 X '3-7/8 inch |
| Weight(kg) | - |
| Terminals | |
| Line In | RCA (Ni) |
| Speaker Output | MOLEX Connector with AWG16 200mm Wire |
| AUDIO SECTION | |
| Speaker Level Input Sensitivity | 4.0 V - 12.0 V |
| Terminals | |
| Battery & Ground | Screw Type Terminal Block (Ni) (M4) |
| AUDIO SECTION | |
| Filter Selector 1 | - |
| RCA Input Sensitivity | 0.2 V - 5.0 V |
| High-Pass Filter | - |
| Low-Pass Filter | Built in Variable Low-Pass Filter (50Hz-200Hz, -24dB/oct) |
| Specifications | |
| Speaker Impedance | 4Ω (2Ω to 8Ω allowable) |
| Bridged connection | - |
| Input Impedance | 10k ohm |
| Frequency Response | 20 Hz-200Hz (+0dB, -3dB) |
| Signal to Noise Ratio | 97dB (Reference: Rated Power into 4Ohms at 14.4V) |
| Maximum Power Output | |
| Maximum Power Output | 600W |
| CEA-2006 Primary Ratings | |
| Signal-to-Noise Ratio | 78dBA (Reference: 1Watt into 4Ohms) |
| Power Output | 200 Watts RMS x 1 at 4 Ohms and ≤1%THD+N |
| General | |
| Current Consumption | 20 A |
