Sanus Fixed-Position Wall Mount For 37" to 90" Flat-panel TVs - LL22-B3



In-store

Literature

Fixed-Position Wall Mount For 37" – 90" Flat-Panel TVs

The SANUS LL22 is a fixed-position wall mount for 37" – 90" flat-panel TVs up to 175 lbs / 79.55 kg. SANUS' unique ProSet™ post-installation height and leveling adjustments ensure TVs are always perfectly positioned after hanging. Quick-release tabs allow the TV to unlock instantly from the wall plate for easy installation, while its low-profile design places the TV nearly flush to the wall for a clean appearance. The innovative ClickStand™ feature holds the TV away from wall for easy cable installation and maintenance, then snaps shut to secure the TV to the wall plate. The LL22 features an open wall plate design that provides ample room for cable routing, and ClickFit™ technology allows a surge protector to attach easily to the center of the mount, so it stays hidden yet easily accessible. The TV can also be shifted left and right on the wall plate for perfect placement, even with off-center studs. Powder-coated steel construction offers strength and durability. Universal mounting brackets. Compatible with the VMA201 soundbar speaker mount. Mount now fits TVs 37” – 90”, and all current LL22 models have been tested for compatibility with the updated size range.

Product Features

  • Conceal unsightly cables
  • Expandable TV brackets ensure a perfect fit
  • Hardware included
  • Hide accessories, like surge protectors, behind your TV
  • Leveling adjustments allow TV to be perfectly positioned after hanging
  • Our TV Mount products are Safety Tested and UL Certified
  • Perfect for viewing TV at eye level
  • Position your TV as close to the wall as possible
  • Pull down on hidden straps to access cables behind your TV
  • Slide TV side-to-side for perfect positioning on the wall
  • VMA201-compatible

Tools You Will Need For Installation

  • 3/16" Drill Bit
  • 1/2" Masonry Bit (Concrete Installations)
  • 1/2" Socket Wrench
  • Awl
  • Electric Drill
  • Level
  • Pencil
  • Phillips Head Screwdriver
  • Stud Finder
Specifications
Product Width30.00" / 76.20cm
Product Height18.25" / 46.36cm
Product Depth1.50" / 3.81cm
Product Weight12.50lbs / 5.67kg
TV Size Range37" - 90" / 93.98cm - 228.60cm
Maximum TV Weight175lbs / 79.38kg
Universal MountingYes | 75 x 100 through 708 x 440
