30" Bosch 500 Series Black Frameless Electric Cooktop - NEM5066UC

$1,649⁰⁰

Save $200⁰⁰

as low as
$137.42

Per month over
12 months.

Not Currently in Stock. Order Lead Times May Vary. This item may be purchased or ordered by visiting any of our retail store locations

Literature

Design

Performance

Safety

2-Level Heat Indicator - Warns if Cooktop is Warm or Hot

SPECIFICATION RANGES
Gross weight (lbs)	34 lbs
Minimum distance from rear wall (in)	2"
Net weight (lbs)	25 lbs
Minimum distance from counter front (in)	2 1/4"
Product packaging dimensions (HxWxD) (in)	7 7/8" x 37 3/8" x 24"
Required cutout size (HxWxD) (in)	4" x 28 7/8" x 20"
Overall appliance dimensions (HxWxD) (in)	1/4"+4" x 31" x 21 1/4"
Heating Technology	Electric
Frequency (Hz)	60 Hz
Plug type	No plug
Current (A)	30/30 A
Volts (V)	240/208 V
Watts (W)	7,200 W
Sealed Burners	No
Approval certificates	CSA
Dimension of 4th heating element (in)	9"
Power of 4th heating element (W)	2.5 kW
Location of 4th heating element	front right
Dimension of 3rd heating element (in)	6"
Power of 3rd heating element (W)	1.2 kW
Location of 3rd heating element	back right
Dimension of 2nd heating element (in)	7"
Power of 2nd heating element (W)	1.8 kW
Location of 2nd heating element	back left
Knob Material	Plastic
Number of Burner	4
Power of 1st heating element (W)	0.7 ; 1.7 kW
Dimension of 1st heating element (in)	7"; 5"
Location of 1st heating element	front left
