Rockford Fosgate Power Series Harley-Davidson Road Glide 6.5 Inch Full Range Fairing Speakers - TMS6RG

$62999
Save $11000
Or
as low as
$105.00
Per month over
6 months.


Available to order

Literature

The TMS6RG is a full range coaxial speaker designed to fit the fairing speaker locations on select model Harley-Davison® Road Glide® Motorcycles. It features a Neodymium motor structure driving a co-molded, reinforced polypropylene cone with Santoprene surround. It also features an ultra-efficient 25mm dome tweeter with integrated phase plug and is made water/weather resistant with the addition of a Santoprene front isolation spider connecting between the tweeter housing and cone assembly. The speaker mounts using the factory hardware and comes with new grille assemblies.  See compatibility chart for fitment.

Overview

The TMS6RG full range coaxial speaker is designed for direct fitment applications on select (see compatibility chart) Harley-Davidson® Road Glide® motorcycles in the upper fairing locations. This speaker directly replaces the existing factory speakers using the factory mounting hardware and speaker connectors. It features a compact Neodymium motor structure driving a co-molded, reinforced polypropylene cone with Santoprene surround This ensures that you get maximum frequency response and output in both the mid and low frequency range. It also features an ultra-efficient 25mm dome tweeter with integrated phase plug for crisp clear highs even at highway cruising speeds. It is made water/weather resistant with the addition of a Santoprene front isolation spider connecting between the tweeter housing and cone assembly. The speaker requires no modification of the factory location and comes with new grille assemblies. Harley-Davidson® and Road Glide® are registered trademarks of Harley-Davidson Motor Company

  • Element Ready design that is weather and water resistant
  • Ultra‐Efficient 25mm Proprietary Film Dome Tweeter
  • Neodymium Tweeter with Integrated Phase Plug and ASA Grill
  • Carbon‐Fiber Re‐Inforced Polypropylene Cone
  • Santoprene VAST Surround
  • Co‐Molded Cone and Surround
  • Santoprene Front Isolation Spider
  • Poly‐Cotton Spider
  • High Power 35mm Voice‐Coil
  • Ultra‐Efficient Neodymium Ring Magnet Motor
  • Ultra‐High Temperature Glass Re‐Inforced Polymer Frame
  • Integrated Spade Terminals
  • Integrated 6dB Crossover with High Power Polyester Capacitor
  • Low Profile Coaxial Tweeter Design
  • Discreet (Hidden) Tweeter Wire
  • Designed for 1998‐2013 Harley-Davidson® Road Glide® Fairing Locations
  • NOTE: Installation on CVO™ and Screaming Eagle™ models are not plug-n-play and will require modification
  • 2-Year Warranty

Technologies

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers that provide superior heat dissipation (up to 100° at full power levels). Unlike traditional plastic substitutions, aluminum acts like a heat-sink to quickly dissipate thermal build-up on the voice coil. This keeps subwoofers cool during high SPL conditions.

Element Ready - Motorcycle Solutions

These models are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

CEA-2031 (speakers)

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

VAST Surround (speakers)

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Specifications
Speaker Type2-Way Coax
Frequency Response (Hz)56 Hz - 20 kHz
Midrange Size (Nominal Diameter)6.5"
Power Handling (RMS)75 Watts RMS
Power Handling (MAX)150 Watts MAX
Grille/Trim Ring IncludedYes
Mounting HardwareYes
Sensitivity (dB @ 2.83V/1M)94 dB
Nominal Impedance (Ohms)4-Ohm
Voice Coil Diameter (in/mm)1.40"
(35.6 mm)
CrossoverBuilt-in tweeter crossover
Included In The Box(2) Speakers
(2) Speaker Grilles
(1) Hardware Pack
Sensitivity (dB @ 1W/1M)91 dB
