Rockford Fosgate Punch P3 2-Ohm DVC Subwoofer - P3D2-12

$34999
Save $7000
Or
as low as
$58.33
Per month over
6 months.


  • Delivery
    Pick Up
    You have selected the option to deliver this product.

    At this point of time, online shopping is available only in British Columbia.

    Add to cart
    Enter the postal code
Available to order

Literature

The P3D2-12 is the best performing Rockford Fosgate Punch series subwoofer. Built to max out your car audio system, the P3 12” features Dual 2-Ohm voice coils (DVC), 600 Watts RMS of power handling, and accommodates a grille insert using the included cast aluminum trim ring. The  P3D2-12 12 inch car subwoofer also includes:

Overview

The P3D2-12 is Rockford Fosgate's best performing Punch series subwoofer for cars and trucks. The P3 12 inch subwoofers now feature anodized aluminum cones and dustcaps along with unique spider venting to keep the motor cooler than previous versions. These feature VAST technology to increase surface cone area up to 25% and a FlexFit basket for extreme car and truck installations. Best of all, a new hybrid stamp-cast basket offers the best of both worlds by providing super strength while minimizing weight and resonance. Looking for more options? Check out all of our subwoofers here.

  • Custom 10-AWG nickel plated push terminals
  • Dual linear spider with embedded 16 AWG tinsel leads
  • Extended pole piece and bumped vented backplate
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Anodized aluminum cone and dustcap
  • Protective PVC textured magnet cover
  • Diamond cut cast aluminum trim ring with optional grille
  • StampCast basket with integrated spider venting
  • 1 Year Warranty

Technologies

Stitched Tinsel Leads

Improved reliability and performance by reducing fatigue and possible shorting.

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

VAST Surround - Subs

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers that provide superior heat dissipation (up to 100° at full power levels). Unlike traditional plastic substitutions, aluminum acts like a heat-sink to quickly dissipate thermal build-up on the voice coil. This keeps subwoofers cool during high SPL conditions.

FlexFit Basket - Subwoofer

The slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position.

Specifications
Size12"
Nominal ImpedanceDual 2-Ohm
Power Handling (Watts RMS)600 Watts RMS
1200 Watts Max
Magnet Weight (oz)96 oz. (2.73 kg.)
Voice Coil Diameter2.5" (65.5 mm)
Mounting Depth6.66 in. (169.3 mm)
Woofer Displacement0.106 cu. ft. (3.0 Liters)
Re (Ohms)3.20
Speaker ConnectorDual 10 AWG compression
Shipping Weight20.9 Lbs. (9.48 kg)
SPL (dB @ 1w/1m)85
Fs (Hz)26.5
Qts0.49
Qes0.53
Qms6.70
Cutout Diameter11.25 in. (285 mm)
Le (mH)4.25
Vas (Liters)57.7
Xmax (mm)15.2
Sd (cm2)570
Subwoofer TypeStandard
Voice Coil TypeDual Voice Coil
Sealed Box Volume (Vb)1.02 cu. ft. (28.8 Liters)
Vented Box Volume (Vb)1.79 cu. ft. (50.6 Liters)
