The P16 is a 6” 2-way shallow full-range speaker rated at 55 watts RMS designed for fanatics needing a factory replacement driver. Package includes two speakers with grilles, integrated high-pass crossovers and mounting hardware.
Overview
Fanatics that need a great sounding speaker to replace factory installed garbage will certainly benefit from this Punch series full-range speaker. The P16 offers a Flex Fit™ basket to ensure compatibility with odd shaped factory speaker locations and an ICC (Integrated Concealed Crossover), eliminating the need to mount any black boxes.
- FlexFit basket design
- OEM adapter plate included
- PEI dome tweeter
- Butyl midrange rubber surround
- Injection molded mineral filled polypropylene cone
- 1 Year Warranty
Technologies
Klippel Verified
Klippel is a speaker certification program allowing us to deliver the best possible speakers.
CEA-2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
VAST Surround (speakers)
The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier installation.
FlexFit Basket - Speaker
The slot mounted frame pattern allows for variable adjustments to the mounting position.
Multi-OEM Adapter
The Multi-OEM Adapter plate allows round component or full-range speakers to fit in certain OEM openings. This allows the speaker the capacity to fit more vehicles.
| Specifications | |
|---|---|
| Nominal Impedance (Ohms) | 4-Ohm |
| Midrange Size (Nominal Diameter) | 6" |
| Midrange Mounting Depth | 1.89" (48mm) |
| Tweeter Size (Nominal Diameter) | 0.75" (19.0mm) |
| Tweeter Mounting Depth | n/a |
| Crossover | Built-in tweeter crossover |
| Sensitivity (dB @ 1W/1M) | 88dB |
| Mounting Hardware | Yes Includes (1) pair 5"x7" / 6"x9" adapter plates |
| Speaker Type | 2-Way Coax |
| Power Handling (RMS) | 55 Watts RMS 110 Watts Max |
| Grille/Trim Ring Included | Yes |
| Shipping Weight | 5.8 Lbs. (2.63kg) |
| Frequency Response (Hz) | 65Hz - 22kHz |
