Siri with Apple CarPlay
Easily access the iPhone features you know and love, just by talking to Siri. Music, maps, phone calls and messages are all under your control.
Voice Control with Android Auto
Use voice commands to dictate messages, take phone calls, or get help from Google Maps. You can even control music playback, just by talking.
WebLink™ Cast compatible
WebLink™ is a lightweight app delivery platform designed especially for in-vehicle use. Using the Android or iOS device connection, it is now possible to mirror your smartphone screen right on the car audio display—for reliable, responsive infotainment anytime on the road.
Easy installation with a compact rear chassis
Despite its double-DIN display, the rear chassis is far smaller than conventional double-DIN units. This makes for much easier installation and leaves plenty of room for cabling and other accessories in the space behind the display.
A/V input connectivity
A composite video and stereo audio input terminal enables connection with an external source device.
Build your own sound system
With the three pre-outs you can add components of your choice, like extra amplifiers or subwoofers.
Rear camera ready for easy reversing
If you've got a rear camera installed, you can use it to help you park. Whenever you tap the rear camera icon or put your vehicle in reverse, the video feed instantly comes up on screen. Customisable guidelines help you to back in smoothly and safely.
Bluetooth® wireless technology
Make hands-free calls and stream wireless audio from your smartphone with Bluetooth®.
Powerful, clear amplification
Advanced signal processing from the 4 x 55 W Dynamic Reality Amp 2 removes interference, so music sounds clear and detailed, even when you crank up the volume.
Dynamic Stage Organizer creates virtual speakers on your dashboard
Sound waves are directional, especially in the higher frequencies—so if your speakers are positioned low in your doors, high-frequency sounds are often lost, reducing clarity and instrument separation. Dynamic Stage Organiser uses digital signal processing to lift the sound, improving stereo positioning so music sounds like it's coming from right in front of you.
FLAC compatibility lets you play lossless audio files, so you can enjoy every detail of the music.
SiriusXM® Radio ready
Connect your SiriusXM® Radio satellite tuner (not supplied) to enjoy commercial-free music, sports, news and entertainment.
With the Quick Wake-up feature, you're ready to go, right after turning the ignition.
Anti-glare clear responsive touchscreen
The anti-glare 6.95 in (17.6 cm) touchscreen gives you intuitive control over music playback, making phone calls and more.
|Size & Weight|
|Dimensions (W x H x D)||178 x 100 x 139 mm|
|Output Power||55 W x4|
|Pre Out||3 Pre (Front/Rear/Sub x 1)|
|Rear View Camera in||Yes|
|USB||Yes (Rear x1)|
|DSO (Dynamic Stage Organizer)||Yes|
|Equalizer||10-band Graphic Equalizer|
|EXTRA BASS||Yes (Off/1/2)|
|Preset||FM18 / AM12|
|RDS / EON||Yes (RBDS)|
|HFP 1.5||Yes (1.6)|
|Speed Dial||Yes (6 memories)|
|Recent Calls (# of)||Yes|
|Last Dialed Call||Yes (select from the dialled call history)|
|Phonebook Access via PBAP||Yes|
|Alphabetical Phonebook Sorting||Yes|
|Ring Volume Level Control||Yes|
|Call Volume Level Control||Yes|
|Phone Battery Level Reminder||Yes|
|Signal Strength Indication||Yes|
|Bluetooth Audio Features|
|Audio Codec (Bluetooth Audio)||SBC / AAC|
|Pause (Bluetooth Audio)||Yes|
|CUE / REV||Yes|
|Group (Folder) +/-||Yes|
|Audio Level Adjustment||Yes (–6 dB to +6 dB)|
|Repeat Control (Audio Device side)||Yes|
|Shuffle Control (Audio Device side)||Yes|
|Meta Data Indication||Yes|
|Panel Surface Finish Color||Black|
|Key Illumination||Yes (White)|
|LCD Type||TFT Active Matrix|
|Screen Aspect||17: 9|
|Screen Diagonal (inch / mm)||6.95 inch|
|Screen Size (W x H mm)||156.6 x 81.6 (mm)|
|Resolution (DOT)||800 x 480|
|KEY ILLUMINATION||Yes (White)|
|Touch Panel||Yes / Resistive / AG|
|Parking Line Adjust||Yes|
|Aspect Ratio Select||Yes|
|Rear View Camera-In Marker Setting||Yes|
|USB Mass Storage Device Control Feature|
|USB Device Control (Repeat)||TRACK/FOLDER/DRIVE|
|USB Device Control (Shuffle)||OFF/FOLDER/DEVICE|
|USB Device Control (Pause)||Yes|
|USB Device Control (Resume Play)||Yes|
|USB Device Control (Audio Codec)||PCM/MP3/WMA/AAC/FLAC|
|USB device control (audio playable file extension)||.wav/.mp3/.wma/.m4a/.flac|
|USB Device Control (Video Codec)||MPEG4-SP / AVC (H.264 Baseline) / WMV / MKV / XviD|
|USB device control (video playable file extension)||.mp4/.wmv/.mkv|
|Menu||English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian|
|Caution||English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian|
|ID3 Tag||English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian|
