Sony Class D 4 Channel Stereo Power Amplifier - XMS400D
| Size & Weight | |
|---|---|
| Dimensions (W x H x D) | 62.6 x 37.3 x 162.8 |
| Weight | 0.46 kg |
| Amplifier | |
| Channel Configuration | 4ch |
| High Pass Filter | 120 Hz |
| High Pass Filter Slope | 12dB/oct |
| Low Pass Filter | 120 Hz |
| Low-Pass Filter Slope | 12dB/oct |
| Rated Output Power, RMS 20 - 20000 Hz | |
| Max. Channel Configuration at 4 ohm (W) / THD (%) | 45 W x 4/1.0% |
| Max. Channel Configuration at 2 ohm (W) / THD (%) | 45 W x 4/1.0% |
| Maximum Output Power (1 kHz) | |
| Max. Channel Power Configuration at 4 ohm | 100 W x 4 |
| General Features | |
| Frequency Response | 20-20 kHz |
| Tolerance | +0.5/-3dB |
| Signal to Noise Ratio | 100dB |
| Total Harmonic Distortion at 1 kHz (%) | 0.08% |
| DETAILS | |
| CTA Power Output | 45 W x 4 |
| CTA SN Ratio | 83 dBA |
| MOSFET | Yes/Yes |
| Line In: Input Sensitivity | 1 V/8 V |
| Current drain (A) - rated output power at 4 ohm | 15 A |
