- Peak Power 1300W
- PP X-motif Cone with Diamond Array Pattern
- Closed Yoke with Advanced Airflow Control
- Stress Controlled Spider
- Robust Thermal Management System
X-Motif Cone with Diamond Array Pattern
X-Motif Cone controls resonance frequency and cuts unnecessary frequency, delivering powerful and solid bass response.
Closed Yoke with Advanced Airflow Control
The KFC-W3041 has a robust thermal management system implemented. with an Aluminum Bobbin, Closed Yoke Design, and Advanced Airflow Control.
Stress Controlled Spider
Computer-optimized damper controls stress and increases mechanical durability.
The Best Match
KFC-W3041 subwoofer is precisely power matched with the KAC-D5101 amplifier.
Optional CA-121G Subwoofer Grille Ready
Weight | |
---|---|
ACCESSORY | Warranty Card |
ACCESSORY | Instruction Manual |
Weight of Magnet | 1560 g , 54.9 oz |
Gross Weight | 5.0 kg , 11.0 lb |
Woofer without Gasket | 4.2 kg , 9.3 lb |
Dimension | |
Mounting Depth | 137mm , 5 - 3/8 inch |
Depth | 155.4mm , 6 - 1/8 inch |
Cut-out Diameter | 279mm , 11 inch |
Height | 326mm , 12 - 13/16 inch |
Width | 326mm , 12 - 13/16 inch |
MOUNTED SPEAKER | |
Magnet | Ferrite , φ134-φ70-t30 |
Gasket | ABS |
Basket | Steel |
Surround | Urethane |
Cap | Injection PP |
Diaphragm | Paper |
Size | 300mm , 12 inch |
ELECTRICAL | |
Frequency Response (Hz) | 29 ~ 300 |
Sensitivity (dB at 1m) | 85 |
RMS Power (W) | 300 |
Peak Input Power (W) | 2000 |
Impedance (Ω) | 4 |
Weight | |
SPECIAL FEATURE | Injection PP X-motif Cone with |
SPECIAL FEATURE | Diamond Array Pattern |
SPECIAL FEATURE | Closed Yoke with Advanced |
SPECIAL FEATURE | Airflow Control |
SPECIAL FEATURE | Aluminum Bobbin |
