- 420 Segment 3 Line Text Display
- Amazon Alexa Ready
- Built-in HD Radio Tuner
- Bluetooth Direct Access Button
- Variable Color Illumination
- 200mm Escutcheon Included
- Equipped with 2 USB Ports
- 3 Preouts 5.0V
Smartphone Connectivity
Enjoy convenient control of popular apps like Spotify and Pandora,built-in Bluetooth for hands-free calls and streaming music,as well as the ability to use your smartphone like a wireless remote control.
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats,including compatibility with FLAC files. Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.
Additional Features
Match Your Mood with Variable Color Illumination
Bright variable color LEDs can be adjusted to match any color dash lighting.
Adjustable 3-Zone Variable Color Illumination
You can adjust the front panel illumination into 3 separate color zones.
200mm Escutcheon Included
A 200mm escutcheon is included to help make the fit seamless in many of the latest model Japanese and other select cars.
Equipped with Dual USB Ports
Play your music from one USB port and use the other to charge your device, or charge both at the same time.
SiriusXM Radio Ready
Access additional music, sports and entertainment content on the go with SiriusXM Radio.
Built-in HD Radio Tuner
HD Radio has the best selection of local radio with amazing features and no monthly fees. HD Radio provides CD sound quality from digital FM stations and FM sound quality from digital AM stations. You can even access additional HD multicasting stations that are not available on traditional analog radio.
Spanish and French Text Display
On-screen display menu now available in Spanish and French.
Remote Control (Optional)
Remote control (KNA-RCDV331) is optionally available.
KNA-RCDV331
Wireless Remote for Navigation, Multimedia and Audio Receivers
| USB I/F | |
|---|---|
| FLAC Decode | FLAC file (Up to 24bit/96kHz) |
| WAV Decode | Linear-PCM |
| AAC Decode | AAC-LC ".aac",".m4a" files |
| WMA Decode | Compliant with Windows Media Audio |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| Maximum Supply current | DC5V(DC logo) 1.5A |
| File System | FAT12 / 16 / 32 |
| USB | USB 1.1 / 2.0 High Speed |
| CD | |
| Speaker Impedance(Ω) | 4 to 8Ω |
| Preout Impedance(Ω) | =<600Ω |
| Preout Level(mV)/Load -Unbalanced | 5000mV/10kΩ |
| WAV Decode | - |
| AAC Decode | AAC-LC ".aac" files |
| WMA Decode | Compliant with WINDOWS MEDIA AUDIO |
| Dynamic Range | 91dB |
| Channel Separation | 84dB |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| S/N Ratio (dB) | 96dB(1kHz) |
| Total Harmonic Distortion | 0.01%(1kHz) |
| Frequency Response | 20Hz to 20kHz(±1dB) |
| Wow & Flutter | Below Measurable Limit |
| Spindle Speed | 500 to 200rpm (CLV) |
| Digital Filter(D/A) | 8 Times OverSampling |
| Laser Diode | GaAlAs |
| (±3.0dB) | |
| S/N | 70dB(STEREO) |
| Digital AM | |
| Frequency Response | 40Hz-15kHz |
| (Frequency step) | (10kHz) |
| Frequency Range | 530kHz - 1700kHz |
| AM | |
| Usable Sensitivity | 29dBμ (28.2μV) |
| Frequency Range | 530kHz to 1700kHz |
| (Frequency step) | (10kHz) |
| (±3.0dB) | |
| S/N | 75dB(STEREO) |
| Digital FM | |
| Frequency Response | 20Hz-20kHz |
| (Frequency step) | (200kHz) |
| Frequency Range | 87.9MHz - 107.9MHz |
| (±3.0dB) | |
| Stereo Separation | 40dB(1kHz) |
| S/N | 68.0dB(MONO) |
| FM | |
| Frequency Response | 30Hz to 15kHz |
| DIN S/N:46dB | (1.580μV/75Ω） |
| Quieting Sensitivity | 15.2dBf |
| S/N 30dB | (0.63μV/75Ω） |
| Usable Sensitivity | 7.2dBf |
| (Frequency step) | (200kHz) |
| Frequency Range | 87.9MHz to 107.9MHz |
| GENE | |
| Net Weight (Trim plate and Mounting sleeve: Included) | 1.7(kg) 3.8(lbs) |
| (D) | 156(mm) 6-1/8(in) |
| (H) | 111(mm) 4-3/8(in) |
| Installation Size (W) | 182(mm) 7-3/16(in) |
| Operating voltage | 12V DC car battery |
| Bluetooth | |
| Profile | AVRCP 1.6.1 (Audio/Video Remote Control Profile) |
| Profile | PBAP(Phonebook Access Profile) |
| Profile | A2DP(Advanced Audio Distribution Profile) |
| Profile | SPP(Serial Port Profile) |
| Profile | HFP 1.7.1 (Hands Free Profile) |
| Maximum Communication range | Line of sight approx.10m(32.8ft) |
| RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
| Frequency Range | 2.402 to 2.480GHz |
| Version | Bluetooth 4.2 |
| TONE | |
| Band13 | 16kHz ±9dB |
| Band12 | 10kHz ±9dB |
| Band11 | 6.3kHz ±9dB |
| Band10 | 4kHz ±9dB |
| Band9 | 2.5kHz ±9dB |
| Band8 | 1.6kHz ±9dB |
| Band7 | 1kHz ±9dB |
| Band6 | 630Hz ±9dB |
| Band5 | 400Hz ±9dB |
| Band4 | 250Hz ±9dB |
| Band3 | 160Hz ±9dB |
| Band2 | 100Hz ±9dB |
| Band1 | 62.5Hz ±9dB |
| AMP | |
| Full Bandwidth Power (at less than 1%THD) | 22Wx4 |
| Input | |
| Input Maximum Voltage | 1000mV |
| Input Impedance | 30kΩ |
| AMP | |
| Maximum Power | 50Wx4 |
| AUX | |
| Frequency Response | 20Hz to 20kHz ±3dB |
