General Features
- Peak Power : 160W
- RMS Power : 40W
- Sensitivity : 87dB/ W at 1 m
- Frequency Response : 76Hz 21,000Hz
Woofer
- Woofer Size: 5-1/4 in (130mm)
- Woofer Diaphragm: Injection PP cone
Tweeter
- Tweeter Size: 1 in (25mm)
- Tweeter Diaphragm: Soft Dome
Dimensions (without grill)
- Width: 5-3/16 in (132mm)
- Height: 5-3/16 in (132mm)
- Depth: 2-15/16 in (75mm)
- Mounting Depth: 2-3/8 in (60mm)
| Specification | |
|---|---|
| Model Name | KFC-X134 |
| System | 2way-2speaker |
| Power Handling | |
| Peak Input Power | 160W |
| Maximum Input Power | 70W |
| Rated Power | 35W |
| RMS Power | 40Watts RMS |
| Impedance | 4Ω |
| Sensitivity | 87dB/ W at 1 m |
| Frequency Response | 76 Hz~21,000 Hz |
| Woofer | |
| Diaphragm | P.P. Cone , Gray |
| Size | Oversized 130 mm , 5-1/4 inch |
| Surround | Rubber |
| Basket | Steel |
| Magnet | Ferrite , 80 x "13 |
| Size | |
| Size | 25 mm , 1 inch |
| Magnet | |
| Magnet | Nd , Up to Engineer |
| Dimension | |
| Width | 160.0 mm , 6-5/16 inch |
| Height | 160.0 mm , 6-5/16 inch |
| Depth | 81.5 mm , 3-3/16 inch |
| Width | 132.0 mm , 5-3/16 inch |
| Height | 132.0 mm , 5-3/16 inch |
| Depth | 74 mm , 2-15/16 inch |
| Cut-out Diameter | 120.0 mm , 4-3/4 inch |
| Tweeter Height | 14 mm , 9/16 inch |
| Mounting Depth | 60.0 mm , 2-3/8 inch |
| Accessory | |
| Adhesive Tape | ○, 1 set |
| Speaker Cord | 0.3 m, 1 set |
| Tweeter | with Woofer Frame , -6dB/oct |
| Binding Head Tapping Screw | φ4 x 25 mm , 8 pcs |
| Speed Nut | φ4 , 8 pcs |
