- Peak Power 400W
- Conformal Coating for Marine and Other use.
- Speaker Level Input with Signal Sensing Turn on.
- Bridgeable Connection.
- Compact design ( W)5-11/16" x (H)1-3/4" x (D)3-7/8"
Key Features
- CTA-2006 Compliant
- Class D
- 2 Ohms Load Capability
- Speaker Level Input
- Signal Sensing Turn-on
- Variable Low-Pass / High-Pass Filter
- Conformal Coating
- Terminal Cover
- Power MOS-FET Switching Power Supply
- Extruded Aluminum Heat Sink Design
- A B Independent Gain Adjustment
Multi-Application
For Automobile
For Marine
For ATV
For Motorcycle
KAC-M1814 Compact Class-D amplifier supports louder volume for Car, Marine and Motorsports users with low-noise.
Plastic covered connector helps to keep out water and dust.
Conformal Coating provides vibration resistance and helps prevent the PCB from rusting.
Pre-amp and Power-amp sections are separated to reduce radiation noise.
Compact design with controlable interface to adjust the sound from a receiver.
- Filter Frequency Control (A.ch/B.ch)
- Filter Switch to apply HPF / OFF / LPF (A.ch/B.ch).
- Line In terminal
- Input Sensitivity Control (A.ch/B.ch)
TERMINAL | |
---|---|
RCA | A/B |
Connector with DC Cable | Yes |
AUDIO SECTION | |
Speaker Level Input Sensitivity | 4.0 (V) - 12.0 (V) |
RCA Input Sensitivity | 0.2 (V) - 5.0 (V) |
High-pass Filter | 50-200Hz, -12dB/oct (A/B CH) |
Low-pass Filter | 50-200Hz, -12dB/oct (A/B CH) |
Specifications | |
Bridged Connection | 4Ω to 8Ω allowable |
Speaker Impedance | 4Ω ( 2Ω to 8Ω allowable) |
Input Impedance | 10k ohm |
Frequency Response | 20Hz-20kHz (+0dB, -1dB) |
Signal to Noise Ratio | 98dB (Reference: Rated Power into 4Ohms at 14.4V) |
RMS Power at 14.4V | |
A/B (Bridged 4Ohms) | 90Watts RMS x 2 at 4 Ohms, 1kHz, ≤1%THD+N |
A/B (2 Ohms) | 45Watts RMS x 4 at 4 Ohms, 1kHz , ≤1% THD+N |
CEA-2006 Primary Ratings | |
Signal-to-Noise Ratio | 82dBA (Reference: 1Watt into 4Ohms) |
Power Output | 45Watts RMS x 4 at 4 Ohms, ≤1%THD+N |
General | |
Dimensions(WxHxD) | 145[mm] x 45 [mm] x 99 [mm] 5-11/16 inch x 1-3/4 inch x 3-7/8 inch |
Weight (kg) | 0.7 [kg] 1.5 [lbs] |
Operating Voltage | 14.4V(11-16V allowable) [V] |
Current Consumption | 15 [A] |
Specifications | |
Amplifier Type | Class D |
Maximum Power Output | |
MAX POWER | 400W |
