Mono Monster
This mono CX-Series Amp is now one-ohm stable, giving you even more wiring options for your system! The Class-D CXA1200.1 features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump. A powerful 12dB crossover and 24dB subsonic filter is included, letting you quickly tune your system to perfection. From your dash, a simple turn of the optional CXARC Remote Bass Controller (sold separately) increases your output to fit your choice of music.
CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!
Use the full-range outputs to expand your system with other bass amps, or add a full-range amp to complete your system.
This CX.1 Amplifier delivers as much as 1,200 watts into one bass channel.
- Efficient Class-D amplifier
- Three-second turn-on/off delay to eliminate unwanted interference
- Variable 12dB crossovers provides control to dial in perfect sound
- KickEQ™ 6dB variable bass boost for those additional low frequencies
- 24dB subsonic filter for protection from potentially damaging frequencies
- FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
- Accepts up to 40-volt input signal
- Small footprint for easier installation
- Compatible with CXARC Remote Bass Control
- Vertical mounting hardware included for another unique look
| Specifications | |
|---|---|
| KickEQ™ Boost | Variable 0-6dB @40Hz |
| Subsonic Filter: | 25Hz @24dB/octave |
| Active Crossover: | Variable Lo-pass 50Hz–200Hz, 12dB/octave |
| Signal-to-Noise Ratio: | 95dB |
| Input Sensitivity: | 125mV–5V (Low Level) , 1V–40V (High Level) |
| Frequency Response (Hz): | 25-200Hz |
| Dimensions (in, cm): (all models 2-3/8, 5.9H x 6-3/4, 17W x ...L) | 12, 30.6 |
| CXRC Remote Bass Capable (sold sep.) | yes |
| Power (watts/ch) 1 Ohm | 1200x1 +/-10% |
| Power (watts/ch) 2 Ohm | 1200x1 |
| Power (watts/ch) 4 Ohm | 600x1 |
| MODEL | CXA1200.1 |
