RP-440D SB PASSIVE SOUND BAR
The Reference Premiere Designer On-Wall RP-440D SB is our premium 3-channel passive LCR sound bar. Leveraging the same acoustic technology as our dynamic, detailed, Reference Premiere box speakers in a slim, on-wall solution with an elegant matte finish. Featuring three horn-loaded 1”Titanium Dome Linear Travel Suspension (LTS) tweeters and four 3.5” Cerametallic™ woofers, this premium passive sound bar is the superior choice for minimalist-designed acoustics.
Features:
- Slim On-Wall Solution Matches Today's Ultra-Flat TV's
- 3-Channel Sound Bar Provides Left/Center/Right Speakers in Single Seamless Cabinet
- Reference Premiere Horn Loaded Acoustic Technology
- Flexible Placement
- Triple 1” Titanium Dome Linear Travel Suspension (LTS) tweeter
- Quad 3.5" Cerametallic™ Woofers
- Dual 4-Way Keyholes for secure on-wall mounting
- Magnetic Wrap-Around Grille
- Included glass base for table-top mounting
- Matte Black Painted Finish Blends Seamlessly into Today’s Modern Interiors
90X90 TRACTRIX HORN
The Tractrix® horn geometry helps to improve high-frequency response and extension, while enhancing imaging and dynamics. It also focuses the high frequency sounds towards the listening area, for the cleanest, most natural sound possible.
LINEAR TRAVEL SUSPENSION (LTS) TITANIUM TWEETER
The same tweeter used in the Reference Premiere box line, a Linear Travel Suspension maximizes dynamics for enhanced, detailed performance. LTS Tweeters have been a hallmark of previous Reference lines, making it a core component of some of the best speakers in the world.
SPUN COPPER CERAMETALLIC WOOFERS
Cerametallic woofers represent the pinnacle of Klipsch driver design, maintaining exceptional rigidity, and lightweight construction, for minimal cone breakup and distortion. When paired with the Tractrix Horn-loaded LTS tweeter, it provides speaker efficiency highest in its class.
WRAP-AROUND MAGNETIC GRILLE
Front grill attaches magnetically for an elegant transition from powerful showstopper to discrete performance piece.
TABLE MOUNT INCLUDED
Dual four-way keyholes allows for easy, tight-to-the-wall mounting either vertically or horizontally, while the included glass base provides a luxurious, modern table-top or bookshelf option.
Specifications | |
---|---|
Frequency Response | 65Hz-25kHz +/- 3dB |
Sensitivity | 92dB @ 2.83V / 1m |
Power Handling | 50W / 200W Per Channel |
Nominal Impedance | 8 Ohms Compatible |
Crossover Frequency | 2200Hz |
High Frequency Driver | Thee 1” (2.54 cm) Titanium Dome LTS Tweeter with 90°x90° Tractrix Horn (One Per Channel) |
Low Frequency Driver | Four 3.5” (8.89 cm) Cerametallic Cone Woofers (One each for Left and Right, Two for Center Channel) |
Enclosure Material | ABS |
Enclosure Type | Bass Reflex |
Inputs | Three Sets Single Binding Posts |
Height | 6” (15.24 cm) |
Width | 42" (106.68 cm) |
Depth | 2.4" (6.10 cm) |
Weight | 12 lbs (5.44 kg) |
Finish | Matte Black Paint |
