The P1-1X12 is a single P1 12” vented enclosure with 250 Watts RMS power handling wired to a 4-Ohm load. The enclosure is constructed with 5/8” MDF, covered in high density carpet, and features quick release compression terminals.
The most convenient way to get low frequency bass in your system is to drop-in a Punch Loaded enclosure. We're not talking junk in the trunk, we're talking the same genuine Punch woofers available separately. Punch Loaded enclosures are constructed with durable 5/8" MDF and tuned by our computer aided design software. P1 Loaded Enclosures feature similar tonal performance as P2/P3 models, but are easier to move in-n-out of vehicles due to their lighter weight.
- Constructed with 5/8" MDF
- Proprietary high-flow, low-noise port
- High current binding posts
- 1 Year Warranty
Technologies
CEA-2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
Klippel Verified
Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.
| Specifications | |
|---|---|
| Enclosure Type | Vented |
| Woofer Quantity | 1 |
| Woofer Size | 12" |
| Shipping Weight | 46.1 Lbs. (20.91 kg) |
| Speaker Connector | Up to 10 AWG compression terminals |
| Woofer Series | Punch P1 (P1S4-12) |
| CEA-2031 Compliant | CEA-2031 Guidelines |
| Nominal Impedance (ea) | 4-Ohm Internally wired to create a 4-Ohm amplifier load |
| Power Handling (Watts RMS) | 250 Watts RMS , 500 Watts Max |
| Enclosure Material | 5/8" MDF (Medium Density Fiberboard) |
| Dimensions Box (H x W x D)Wedge (H x W x D1 x D2) | 15.125" x 19.125" x 15.75" (38.4cm x 48.6cm x 40cm) |
