Rockford Fosgate DVC 2Ω Color Optix Marine Subwoofer in White - M1D2-12
Rockford Fosgate DVC 2Ω Color Optix Marine Subwoofer in Black - M1D2-12B
Rockford Fosgate DVC 2Ω Color Optix Marine Subwoofer in White - M1D2-12
Authorized Dealer Price Match Guarantee
Price Match Guarantee
Andre's Electronic Experts offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

In-store

In-store

In-store

More options
Literature

The M1D2-12 Color Optix™ 12” DVC 2-Ohm subwoofers deliver loud, clear, accurate bass, and light the way for your journey! The subwoofers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IP67 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential. ColorOptix™ Speakers Product Overview

Overview

The M1 series of Element Ready™ subwoofers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To compliment the plug and play connectivity and streamline installation, M1 subwoofers are equipped with a VersaSwitch™ to make changing impedance between 1 and 4 ohms as easy as flipping a switch.

  • Optically clear UV stable RGB Lighting Encapsulation
  • Ultra-bright wide-angle RGB LEDs provide rich, reliable illumination
  • Vented motor design with water-repelling nano coated mesh screen
  • 2" (50mm) High Temp Kapton™ Woofer Voice Coil Former
  • Fully insulated silicone tinsel leads
  • 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
  • Zinc Nickel-plated Marine grade brass connection terminals
  • Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
  • Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
  • Linear Synthetic Fiber Blend Spiders
  • Santoprene VAST Surround
  • VAST vertical attach surround technique increases effective radiating cone area up to 25%
  • Co-molded surround and mineral filled polypropylene cone body
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • VERSA switch allows series or parallel wiring with flip of switch without additional wiring
  • 2-Year Warranty

Technologies

Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

ASTM B117 Testing

ASTM B117 500Hr Salt/Fog Testing Standards

ASTM G154 Testing

ASTM G154 500Hr Accelerated UV testing

IPX6 Water Intrusion Rating

Water projected in powerful jets from any direction shall have no harmful effects.

ISO60068-2-64 Testing

ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on watercraft and motorsport applications.

VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

VERSA Switch

Allows you to easily switch Dual Voice Coils into a Series or Parallel configuration.

Specifications
Size12"
Nominal Impedance (Ohms)1-Ohm or 4-Ohm Switchable
Power Handling (Watts RMS)300 Watts RMS
1200W PEAK
Voice Coil Diameter2" (50 mm)
Frequency Response20 Hz - 750 Hz
Magnet Weight (oz)39.75 oz. (1.13 Kg)
Fs (Hz)26
Re (Ohms)3.8
Le (mH)2.02
Qms7.47
Sd (cm2)585.4
Qes0.57
Qts0.53
Vas114.2
SPL (dB @ 1w/1m)92
Xmax (mm)6.0
Woofer Displacement3.49 (0.12 Liters)
Speaker ConnectorDeutsch™
Cutout Diameter10.85" (275.6 mm)
Mounting Depth6.65" (169.1 mm)
Shipping Weight9 Lbs. (4.1 Kg.)
