PowerBass 10 Inch Single 4-Ohm Subwoofer - S1004

Free Shipping
Save $2700
as low as
Per month over
6 months.

  • Delivery
    Pick Up
    You have selected the option to deliver this product.

    At this point of time, online shopping is available only in British Columbia.

    Add to cart
    Enter the postal code
Available to order

  • 10" Single 4-Ohm Subwoofer
  • 275 watt RMS/550 Watts Max
  • Proprietary DDC Coated Paper/Wool Cone
  • Pressed 4-Layer Large Roll Foam Surround
  • 2" Vented BASV Voice Coil Former
  • Perimeter Aero-Vent Voice Coil Cooling Vents
  • Non Resonance DDC Coated Stamped Steel Basket
  • Rubber Mounting Gasket/Trim Ring
  • Chrome Push Terminals
  • Optimally Designed for Both Small Sealed or Ported Enclosures


Our improved S-Series subwoofers bring value to a whole new level. This year we rounded out the line by adding a couple of 8-inch subwoofers. You will be impressed with the oversized motor structure for high-power handling and greater reliability during heavy hitting bass passages.

PowerBass S-Series woofers featuring a 4-layer wool/paper cone now sport a treated non-resonant finished, stamped steel basket that is custom tooled with our distinctive X design. A 2” BASV voice coil former (1.5" on the 8") is used on the 10 and 12-inch models and like the entire Autosound range, we also offer a Large Roll foam surround for precise linear movement of the cone, which equals loud bass.

The S Series subwoofers are well-suited for small sealed or ported enclosures and use dual 4-ohm and single 4-ohm voice coils for multiple bass applications. Now more than ever, our S-Series woofers provide lots of value without sacrificing hard-hitting performance.

Test Impedance: 3.2-ohms
Fs: 33.5 Hz
SD: 330.06 sqCM
Vas: 43.8 Ltr
Cms: 270 uM/N
Mms: 94.2 g
Qms: 5.12
Qes: 0.43
Qts: 0.4
No: 0.29%
Spl: 86.6 dB
Xmax: 9 mm
Mounting Depth: 5.25 in
Cutout Diameter: 9 1/8 (230.1mm)
Motor Structure: 116 oz
Sensitivity (1W / 1M): 86 dB
Material: Pressed Wool / Paper
Voice Coil Size: 2 in
Subwoofer Frequency Range: 33 Hz - 500 Hz
Inputs: Single Coil
BL: 11.6
Nominal Impedance: Single 4-ohm
VC Impedance: 4-ohm
Size: 10 in
Sensitivity: 86 dB
Frequency Response: 33 Hz - 500 Hz
Voice Coil Size: 2 in
Power Handling (RMS/Peak): 275 / 550 watts
