The Power T1000-1bdCP is a 1,000 Watt mono amplifier featuring Constant Power delivering up to 25% more power across all impedance loads. The frequency response of the T1000-1bdCP is optimized exclusively for use with subwoofers.
Overview
The new Constant Power amplifiers are the most powerful amplifiers on the market PERIOD! The T1000-1bdCP is based on the legendary T1000-1bd amplifier design with a proprietary "Constant Power" configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. The T1000-1bdCP, pumps out a heart-stopping Kilowatt, enough power for any reasonably sane subwoofer system.
- 24dB/octave crossover
- 4 Gauge power/ground connectors
- Audiophile grade speaker connections
- MOSFET power supply
- MOSFET output stage
- RCA pass-thru outputs
- Infrasonic filter
- 2-Year Warranty
Technologies
Balanced Differential Inputs
Differential inputs eliminate noise picked up by signal cables.
Constant Power
Constant Power is a patented circuit topology that provides instantaneous delivery of output power over varying impedance loads.
Class BD
Class BD amplifiers have 75-80% efficiency ratings vs. 20-60% efficiency ratings of traditional class A/B amplifiers.
DSM
DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.
CEA-2006 Compliant
Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.
MEHSA3
MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.
Punch Bass EQ
Pioneered by Jim Fosgate in the early 70's, Punch Bass compensates for acoustical problems common in all cars.
Engineered In The USA
These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.
TO-247 MOSFETs
(left-OLD | right-NEW) Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more metal tab area for more power capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in competitor amps.
Specifications | |
---|---|
Cooling | Convection |
Speaker Wire Gauge | 8 AWG to 18 AWG |
Speaker Output Connector | Block |
Power Wire Gauge | 4 AWG |
Power Input Connector | Block |
Visual Indicators | Power (Blue LED) Thermal (Red LED) Protect (Yellow LED) |
Remote Controls | Optional Remote PEQ (overrides built-in Punch Bass) |
Tone Controls | Bass: 0dB to +18dB @ 45Hz |
Crossover Controls | Low-Pass (LP): 35Hz-250Hz @ 24dB/octave Butterworth Infrasonic: 12dB/octave Butterworth, -3dB @ 28Hz |
Signal Output | 1 RCA pair |
Signal Input | 1 RCA pair |
Total Harmonic Distortion (THD+Noise) | 4-Ohm: <1.0% 2-Ohm: <1.0% 1-Ohm: <1.0% |
Efficiency (average) | 85.6% @ 4-Ohm 82.1% @ 2-Ohm 70% @ 1-Ohm |
Circuit Topology Class | Class BD |
Input Sensitivity | 150 mV to 4 V |
Frequency Response | 20Hz to 250Hz +/-0.5dB |
Bridgeable | No |
Dynamic Power (PVC/PowerCube®) | 772 Watts x 1 @ 4-Ohms 1299 Watts x 1 @ 2-Ohms 1395 Watts x 1 @ 1-Ohm |
Rated Power (RMS Continuous Power) | 700 Watts x 1 @ 4-Ohm 1000 Watts x 1 @ 2-Ohm 1000 Watts x 1 @ 1-Ohm |
Total Power (Sum of Rated Power) | 1000 Watts RMS |
Number of Channels | 1 |
Operating Voltage | 9 - 16 VDC |
Recommended Fuse (not included) | 150 A |
Average Current Draw (13.8V Music) | 70 A |
Max. Current Draw (13.8V Sinewave) | 140 A |
Suggested Alternator | 100 A |
Dimensions (H x W x D) | 2.14 x 8.14 x 13.66 (in) 5.44 x 20.68 x 34.69 (cm) |
Shipping Weight | 12.2 Lbs. (5.53 Kg.) |
