When you have no space for bass, our Prime R2SD2-10 shallow subwoofer will satisfy your need. This 10” subwoofer handles 200 Watts RMS and the 2-Ohm Dual Voice Coil design lets you to wire them in various configurations.
When you have no space for bass, our R2 10" shallow subwoofer can help satisfy your need for low frequency music. These drivers can fit in tight spaces due to an elevated motor structure that reduces speaker depth. Mica injected polypropylene cones make sure bass notes are clean and accurate. Stamp-cast baskets feature spider venting typically reserved for traditional depth mounted models to keep the motor cool! These shallow subwoofers are optimized for sealed enclosures.
- 12 AWG compression terminals
- Anodized aluminum voice coil former
- Optimized for sealed enclosures
- Mica injected polypropylene cone
- Linear spider with embedded 16 AWG tinsel leads
- StampCast basket with integrated spider venting
- Integrated PVC trim ring
- Shallow Motor Assembly
- 1 Year Warranty
Stitched Tinsel Leads
Improved reliability and performance by reducing fatigue and possible shorting.
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
Anodized Aluminum Voice Coil Former
Rockford Fosgate subwoofers use anodized aluminum voice coil formers that provide superior heat dissipation (up to 100° at full power levels). Unlike traditional plastic substitutions, aluminum acts like a heat-sink to quickly dissipate thermal build-up on the voice coil. This keeps subwoofers cool during high SPL conditions.
Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.
|Power Handling (Watts RMS)||200 Watts RMS |
400 Watts Max
|Voice Coil Diameter||2" (50 mm)|
|Speaker Connector||Dual 12 AWG compression|
|Shipping Weight||10.588 Lbs. (4.80 kg.)|
|Cutout Diameter||9.125 in. (232 mm)|
|Woofer Displacement||0.037 cu. ft. (1.05 Liters)|
|Nominal Impedance||Dual 2-Ohm|
|Magnet Weight (oz)||45 oz. 1.28 kg.|
|Mounting Depth||3.417 in. (86 mm)|
|SPL (dB @ 1w/1m)||83|
|Voice Coil Type||Dual Voice Coil|
|Sealed Box Volume (Vb)||0.7 cu. ft. (19.8 Liters)|
|Vented Box Volume (Vb)||1.4 cu. ft. (39.6 Liters)|
