- 204 Segment 1 Line Text Display
- Spotify Ready
- Bluetooth Direct Access Button
- Blue/White Color Illumination
- Front USB & AUX IN
- 1 Preout 2.5V

Smartphone Connectivity
Enjoy convenient control of popular apps like Spotify and Pandora,built-in Bluetooth for hands-free calls and streaming music,as well as the ability to use your smartphone like a wireless remote control.

The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats,including compatibility with FLAC files.
Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.

Additional Features
Spanish and French Text Display
On-screen display menu now available in Spanish and French.
TONE | |
---|---|
Band10 | 4kHz ±9dB |
Band9 | 2.5kHz ±9dB |
Band8 | 1.6kHz ±9dB |
Band7 | 1kHz ±9dB |
Band6 | 630Hz ±9dB |
Band5 | 400Hz ±9dB |
Band4 | 250Hz ±9dB |
Band3 | 160Hz ±9dB |
Band2 | 100Hz ±9dB |
Band1 | 62.5Hz ±9dB |
AMP | |
Full Bandwidth Power(at less than 1%THD) | 22Wx4 |
Maximum Power | 50Wx4 |
Input | |
Input Impedance | 30kΩ |
Input Maximum Voltage | 1000mV |
AUX | |
Frequency Response | 20Hz to 20kHz ±3dB |
Speaker Impedance(Ω) | |
FLAC Decode | FLAC file (Up to 24bit/96kHz) |
WAV Decode | Linear-PCM |
AAC Decode | AAC-LC ".aac",".m4a" files |
WMA Decode | Compliant with Windows Media Audio |
MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
Maximum Supply current | DC5V(DC logo) 1.5A |
File System | FAT12 / 16 / 32 |
Speaker Impedance(Ω) | 4 to 8Ω |
Preout Impedance(Ω) | |
Preout Impedance(Ω) | =<600Ω |
Preout Level(mV)/Load | |
-Unbalanced | 2500mV/10kΩ |
CD | |
WAV Decode | - |
AAC Decode | AAC-LC ".aac" files |
WMA Decode | Compliant with WINDOWS MEDIA AUDIO |
MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
Channel Separation | 90dB |
Dynamic Range | 92dB |
S/N Ratio (dB) | 99dB(1kHz) |
Total Harmonic Distortion | 0.02%(1kHz) |
Frequency Response | 20Hz to 20kHz(±1dB) |
Wow & Flutter | Below Measurable Limit |
Spindle Speed | 500 to 200rpm (CLV) |
Digital Filter(D/A) | 8 Times OverSampling |
Laser Diode | GaAlAs |
AM | |
Usable SensitivityS/N:20dB | 29dBμ (28.2μV) |
Frequency Range(Frequency step) | 530kHz to 1700kHz(10kHz) |
FM | |
Stereo Separation | 40dB(1kHz) |
S/N | 64.0dB(MONO) |
Frequency Response(±3.0dB) | 30Hz to 15kHz |
Quieting SensitivityDIN S/N:46dB | 17.2dBf(2.0μV/75Ω) |
Usable SensitivityS/N 30dB | 8.2dBf(0.71μV/75Ω) |
Frequency Range(Frequency step) | 87.9MHz to 107.9MHz(200kHz) |
TONE | |
Band11 | 6.3kHz ±9dB |
Band12 | 10kHz ±9dB |
Band13 | 16kHz ±9dB |
Bluetooth | |
Version | Bluetooth 4.2 |
Frequency Range | 2.402 to 2.480GHz |
RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
Maximum Communication range | Line of sight approx.10m(32.8ft) |
Profile | HFP 1.7.1 (Hands Free Profile) |
Profile | SPP (Serial Port Profile) |
Profile | PBAP (Phonebook Access Profile) |
Profile | A2DP (Advanced Audio Distribution Profile) |
Profile | AVRCP 1.6.1 (Audio/Video Remote Control Profile) |
GENE | |
Operating voltage | 12V DC car battery |
Installation Size(W)(H)(D) | 182(mm) 7-3/16(in) 53(mm) 2-1/16(in)155.5(mm) 6-1/8(in) |
Net Weight(Trim plate and Mounting sleeve: Included) | 1.2(kg) 2.7(lbs) |
