- 205 Segment 1 Line Text Display
- Spotify Ready
- Bluetooth Direct Access Button
- Short Chassis
- Front USB & AUX IN
- 1 Preout 2.5V
Smartphone Connectivity
Enjoy convenient control of popular apps like Spotify and Pandora,built-in Bluetooth for hands-free calls and streaming music,as well as the ability to use your smartphone like a wireless remote control.
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats ,including compatibility with FLAC files.Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.
Short Chassis for Easier Installation than Ever before
With audio receivers shorter in depth than any of our previous models, installation is made easier in a wider range of cars than ever before.
| Speaker Impedance(Ω) | |
|---|---|
| FLAC Decode | FLAC file (Up to 24bit/96kHz) |
| WAV Decode | Linear-PCM |
| AAC Decode | AAC-LC ".aac",".m4a" files |
| WMA Decode | Compliant with Windows Media Audio |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| Channel Separation | 92dB |
| Dynamic Range | 93dB |
| S/N Ratio (dB) | 98dB(1kHz) |
| Frequency Response | 20Hz to 20kHz(±1dB) |
| Maximum Supply current | DC5V(DC logo) 1.5A |
| File System | FAT12 / 16 / 32 |
| Speaker Impedance(Ω) | 4 to 8Ω |
| Preout Impedance(Ω) | |
| Preout Impedance(Ω) | =<600Ω |
| Preout Level(mV)/Load-Unbalanced | |
| -Unbalanced | 2500mV/10kΩ |
| AM | |
| Usable SensitivityS/N:20dB | 29dBμ (28.2μV) |
| Frequency Range(Frequency step) | 530kHz to 1700kHz(10kHz) |
| FM | |
| Frequency Range(Frequency step) | 87.9MHz to 107.9MHz(200kHz) |
| Usable SensitivityS/N 30dB | 8.2dBf(0.71μV/75Ω） |
| Quieting SensitivityDIN S/N:46dB | 17.2dBf(2.0μV/75Ω） |
| Frequency Response(±3.0dB) | 30Hz to 15kHz |
| S/N | 64.0dB(MONO) |
| Stereo Separation | 40dB(1kHz) |
| GENE | |
| Net Weight(Trim plate and Mounting sleeve: Included) | 0.6(kg) 1.3(lbs) |
| Installation Size(W)(H)(D) | 182(mm) 7-3/16(in) 53(mm) 2-1/16(in)155.5(mm) 6-1/8(in) |
| Operating voltage | 12V DC car battery |
| Bluetooth | |
| Profile | AVRCP 1.6.1 (Audio/Video Remote Control Profile) |
| Profile | SPP (Serial Port Profile) |
| Profile | A2DP (Advanced Audio Distribution Profile) |
| Profile | PBAP (Phonebook Access Profile) |
| Profile | HFP 1.7.1 (Hands Free Profile) |
| Maximum Communication range | Line of sight approx.10m(32.8ft) |
| RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 |
| Version | Bluetooth 4.2 |
| Frequency Range | 2.402 to 2.480GHz |
| TONE | |
| Band12 | 10kHz ±9dB |
| Band13 | 16kHz ±9dB |
| Band10 | 4kHz ±9dB |
| Band11 | 6.3kHz ±9dB |
| Band7 | 1kHz ±9dB |
| Band8 | 1.6kHz ±9dB |
| Band9 | 2.5kHz ±9dB |
| Band4 | 250Hz ±9dB |
| Band5 | 400Hz ±9dB |
| Band6 | 630Hz ±9dB |
| AMP | |
| Maximum Power | 50Wx4 |
| Full Bandwidth Power(at less than 1%THD) | 22Wx4 |
| TONE | |
| Band1 | 62.5Hz ±9dB |
| Band2 | 100Hz ±9dB |
| Band3 | 160Hz ±9dB |
| Input | |
| Input Impedance | 30kΩ |
| Input Maximum Voltage | 1000mV |
| AUX | |
| Frequency Response | 20Hz to 20kHz ±3dB |
